» HSS Involute Spline Cutter With PA30
Involute Spline Cutter
● #1 cutter for 12&13 Cuts gears
● #2 cutter for 14-16 Cuts gears
● #3 cutter for 17-20 Cuts gears
● #4 cutter for 21-25 Cuts gears
● #5 cutter for 26-34 Cuts gears
● #6 cutter for 35-54 Cuts gears
● #7 cutter for 55-134 Cuts gears
● #8 cutter for 135 to Rack Cuts gears
Flat Root
Full Fillet
| Module Pitch | Cutter Dia. | Size Hole | 8pcs/set |
| 0.5 | 2-1/2 | 1 | 660-8767 |
| 0.75 | 2-3/4 | 1 | 660-8768 |
| 1 | 3 | 1 | 660-8769 |
| 1-1/4 | 3 | 1 | 660-8770 |
| 1-1/2 | 3 | 1 | 660-8771 |
| 1-3/4 | 3 | 1 | 660-8772 |
| 2 | 3 | 1 | 660-8773 |
| 3 | 3 | 1 | 660-8774 |
| 3-1/2 | 3-1/2 | 1 | 660-8775 |
| 4 | 3-1/2 | 1 | 660-8776 |
| 4-1/2 | 3-1/2 | 1 | 660-8777 |
| 5 | 3-1/2 | 1 | 660-8778 |
| 6 | 3-3/4 | 1-1/4 | 660-8779 |
| Module Pitch | Cutter Dia. | Size Hole | 8pcs/set |
| 0.5 | 2-1/2 | 1 | 660-8780 |
| 0.75 | 2-3/4 | 1 | 660-8781 |
| 1 | 3 | 1 | 660-8782 |
| 1-1/4 | 3 | 1 | 660-8783 |
| 1-1/2 | 3 | 1 | 660-8784 |
| 1-3/4 | 3 | 1 | 660-8785 |
| 2 | 3 | 1 | 660-8786 |
| 3 | 3 | 1 | 660-8787 |
| 3-1/2 | 3-1/2 | 1 | 660-8788 |
| 4 | 3-1/2 | 1 | 660-8789 |
| 4-1/2 | 3-1/2 | 1 | 660-8790 |
| 5 | 3-1/2 | 1 | 660-8791 |
| 6 | 3-3/4 | 1-1/4 | 660-8792 |
Application
Functions For Spline Cutter:
An HSS spline cutter is used to machine splines on shafts or holes, enabling torque transmission between mechanical parts. The high-speed steel material ensures durability and wear resistance during high-speed machining.
Usage For Spline Cutter:
1.Machining Splines: Creates external or internal splines on components.
2.Cutting Keyways: Cuts slots for keys on shafts.
3.Gear Manufacturing: Produces accurate splines for gears.
4.Broaching: Used in broaching processes for internal splines.
Precautions For Spline Cutter:
1.Alignment: Ensure proper tool alignment.
2.Cutting Speed: Adjust speed to avoid overheating.
3.Lubrication: Use cutting fluids to reduce wear.
4.Inspection: Regularly check for tool wear or damage.
5.Safety: Wear safety gear and secure the workpiece.
